MIRI® Humidity Multiroom Incubator

The MIRI® Humidity is a six chamber multiroom benchtop incubator that provides a humidified environment for embryo culture. The robust design enables for quick temperature and gas recovery for optimal embryo culture while preventing vapor condensation.

Embryo Culture

For Embryo Culture

Features

Six (6) completely independent chambers

Superior gas system

Heated lid

Fast temperature and gas recovery

LED display

Optimized heating plates

Easy external validation

MIRI® Data Logger

Humidified environment for embryos

Continuous pH monitoring

Get a Quote Download Catalogue
Product Details MIRI® Humidity Multiroom Incubator General Specifications Ordering Operation Literature & Resources

Parts of the MIRI® Humidity Multiroom Incubator

Parts of MIRI Humidity

Superior Incubation for your Samples

The Esco MIRI® Humidity Multiroom incubator is the best option for securing embryos in your IVF laboratory. With its six (6) independent chambers, not only does it provide embryologists with a bigger capacity to accommodate more embryos, but it gives the ability to ensure that environmental parameters are maintained even when the neighboring chambers are opened. It also gives the best temperature recovery, accuracy, and uniformity in the IVF incubator market with its heated lid design. This feature ensures that temperature around the embryos is maintained both from the bottom and the top where the lid is heated with a set point of 37.2 °C to ensure that exactly 37.0 °C is given to your samples at the embryo level while providing a humidified environment.

Cost-effective and Flexible

The Esco MIRI® Humidity Multiroom incubator provides you with the choice of using pure N2 and CO2 gases or premixed gas. However, using pure gasses has two benefits. Firstly, it is more cost-effective as the incubator can recirculate these gasses. Secondly, it allows the user to adjust the gas concentration as needed for optimal embryo culture protocols in the laboratory. The MIRI® Humidity Multiroom is also compatible with most common brands of culture dishes in the market. Please find below the corresponding capacity per incubator chamber.

Total Capacity

Heating plates customized for several types of dishes:

  • 4 x Falcon® ⌀ 50/60 mm
  • 8 x Falcon® ⌀ 35 mm
  • 4 x Nunc™ ⌀ 54/60 mm
  • 8 x Nunc™ ⌀ 35 mm
  • 4 x VitrolifeDishes
  • 4 x LifeGlobal® GPS Dishes
  • 4 x Nipro™
  • 4 x SparMED Oosafe® 4-well Dishes
  • 4x SparMED Oosafe ⌀ 55/60 mm
  • 8x SparMED Oosafe ⌀ 35 mm

General Specifications of the MIRI® Humidity Multiroom Incubator

Overall Dimensions (W x D x H) 700 x 645 x 280 mm (27.5 x 23 x 6.5") (with a bottle holder attached)
Weight 40 kg (88.2 lbs)
Material Mild Steel / Aluminium / PET / Stainless Steel
Power Supply 115V 60Hz or 230V 50Hz
Power Consumption 300 W
Temperature Control Range 24.9 - 40 °C
*CO2 Gas Consumption <4 Liters per hour
**N2 Gas Consumption <12 Liters per hour
CO2 Control Range 2.0% - 9.9%
O2 Control Range 5.0% - 20.0%
Gas Input Pressure 0.4 to 0.6 bar (5.80 - 8.70 PSI)
Operating Altitude Up to 2000 meters (6560 feet or 80kPa - 106kPa)
Shipping Weight 45 kg (99.2 lbs) (Including the pallet's weight)
Shipping Dimensions 824 x 724 x 489 mm (32.4 x 28.5 x 19.3") (device on the pallet)

* Under normal condition (CO2 set point reached at 6.0%, all lids closed)
** Under normal condition (O2 set point reached at 5.0%, all lids closed)

MIRI® Stacking Frames

Increase your workspace efficiency and maximize space in your IVF laboratory by utilizing the specially crafted MIRI® Stacking Frames


MRA-1014 - MIRI® Stacking Frame for 2 devices

MRA-DRAW - MIRI® Stacking Frame for 2 devices with a drawer


Stacking Frame Specifications

Stacking frame model Dimensions with devices affixed (W x D x H)
MIRI® Stacking Frame for 2 devices 717 x 699,53 x 748 mm (28.2 x 27.5 x 29.4")
MIRI® Stacking Frame for 2 devices with a drawer 717 x 762 x 460 mm (28.2 x 29.0 x 18.1")
On full opening of the drawer: 717 x 1328 x 460 mm (28.2 x 52.3 x 18.1")

Ordering Operation

MIRI® Humidity Multiroom Incubator
Item Code Model Code Description
Unit
2070183 MRI-6A10-H-8 MIRI® Humidity Multiroom Incubator, 230V, 50/60Hz
2070184 MRI-6A10-H-9 MIRI® Humidity Multiroom Incubator, 115V, 50/60Hz
Accessories
1320011 MRA-1007 VOC/HEPA filter (recommended to be replaced every 3 months)
1320142 MRI-DATA Datalogger Package with an Intel® NUC Box, monitor, etc.
1320018 MRA-1014 MIRI® Stacking frame for 2 devices
1320226 MRA-DRAW MIRI® Stacking frame with a drawer for 2 devices
Heating optimization plates
Item Code Model Code Description
1320003 MRA-FD Heating optimization plate for Falcon® Dishes
1320004 MRA-ND Heating optimization plate for NUNC™ Dishes
1320070 MRA-VD Heating optimization plate for Vitrolife® Dishes
1320099 MRA-NID Heating optimization plate for Nipro™ Dishes
1320100 MRA-LD Heating optimization plate for LifeGlobal® GPS Dishes
1320101 MRA-PD Heating optimization plate without footprint for Plain Dishes
1320118 MRA-OD Heating optimization plate for Sparmed - Oosafe®
1320507 MRA-BIRR Heating optimization plate for BIRR Dishes
