MIRI^® Multiroom Incubator

A multiroom incubator for embryo culture with 6 independent chambers preventing cross contamination without causing any disturbance to the neighboring chambers even when the lids are opened/closed.

For Animal IVF & Embryo Culture

Features

Six (6) completely independent chambers

Superior gas system

Heated lid

Fast temperature and gas recovery

LED display

Optimized heating plates

Easy external validation

MIRI^® Data Logger

Space-saving the touchscreen tablet and stacking frame

Continuous pH monitoring

Get a Quote

Download Catalogue

Watch Video

Product Details Parts of the MIRI® Multiroom Incubator General Specifications Ordering Information Literature & Resources

Parts of the MIRI® Multiroom Incubator

Superior Incubation for your Samples

The Esco MIRI^® Multiroom incubator is the best option for securing embryos in your IVF laboratory. With its six (6) independent chambers, not only does it provide embryologists with a bigger capacity to accommodate more embryos, but it gives the ability to ensure that environmental parameters are maintained even when the neighboring chambers are opened. It also gives the best temperature recovery, accuracy, and uniformity in the IVF incubator market with its heated lid design. This feature ensures that temperature around the embryos is maintained both from the bottom and the top where the lid is heated with a set point of 37.2 °C to ensure that exactly 37.0 °C is given to your samples.

Cost-effective and Flexible

The Esco MIRI® Multiroom incubator provides you with the choice of using pure N₂ and CO₂ gases or premixed gas. However, using pure gases has two benefits. Firstly, it is more cost-effective as the incubator can recirculate these gases. Secondly, it allows the user to adjust the gas concentration as needed for optimal embryo culture protocols in the laboratory. The MIRI® Multiroom is also compatible with most common brands of culture dishes in the market. Please find below the corresponding capacity per incubator chamber.

Total Capacity

Heating plates customized for several types of dishes:

4 x Falcon® ⌀ 50/60 mm
8 x Falcon® ⌀ 35 mm
4 x Nunc™ ⌀ 54/60 mm
8 x Nunc™ ⌀ 35 mm
4 x VitrolifeDishes
4 x LifeGlobal® GPS Dishes
4 x Nipro™
4 x SparMED Oosafe® 4-well Dishes
4x SparMED Oosafe ⌀ 55/60 mm
8x SparMED Oosafe ⌀ 35 mm

General Specifications of the MIRI® Multiroom Incubator

Overall Dimensions (W x D x H)	700 x 585 x 165 mm (27.5 x 23 x 6.5")
Weight	40 kg (88.2 lbs)
Material	Mild Steel / Aluminium / PET / Stainless Steel
Power Supply	115V 60Hz or 230V 50Hz
Power Consumption	300 W
Temperature Control Range	24.9 - 40 °C
*CO₂ Gas Consumption	<2 Liters per hour
**N₂ Gas Consumption	<12 Liters per hour
CO₂ Control Range	2.0% - 9.9%
O₂ Control Range	5.0% - 20.0%
Gas Input Pressure	0.4 to 0.6 bar (5.80 - 8.70 PSI)
Operating Altitude	Up to 2000 meters (6560 feet or 80kPa - 106kPa)
Shipping Weight	45 kg (99.2 lbs) (Including the pallet's weight)
Shipping Dimensions	824 x 724 x 489 mm (32.4 x 28.5 x 19.3") (device on the pallet)

* Under normal condition (CO₂ set point reached at 6.0%, all lids closed)
** Under normal condition (O₂ set point reached at 5.0%, all lids closed)

MIRI® Stacking Frames

Increase your workspace efficiency and maximize space in your IVF laboratory by utilizing the specially crafted MIRI^® Stacking Frames

MRA-1014 - MIRI^® Stacking Frame for 2 devices

MRA-DRAW - MIRI^® Stacking Frame for 2 devices with a drawer

Stacking Frame Specifications

Stacking frame model	Dimensions with devices affixed (W x D x H)
MIRI^® Stacking Frame for 2 devices	717 x 699,53 x 748 mm (28.2 x 27.5 x 29.4")
MIRI^® Stacking Frame for 2 devices with a drawer	717 x 762 x 460 mm (28.2 x 29.0 x 18.1")
MIRI^® Stacking Frame for 2 devices with a drawer	On full opening of the drawer: 717 x 1328 x 460 mm (28.2 x 52.3 x 18.1")

Ordering Information

MIRI® Multiroom Incubator
Item Code	Model Code	Description
Devices
2070047	MRI-6A10-8	MIRI^® Multiroom Incubator, 230V, 50/60Hz
2070048	MRI-6A10-9	MIRI^® Multiroom Incubator, 115V, 50/60Hz
Accessories
1320011	MRA-1007	VOC/HEPA filter (recommended to be replaced every 3 months)
1320142	MRI-DATA	Datalogger Package with an Intel^® NUC Box, monitor, etc.
1320018	MRA-1014	MIRI^® Stacking frame for 2 devices
1320226	MRA-DRAW	MIRI^® Stacking frame with a drawer for 2 devices
1320045	MRI-GA	MIRI^® GA CO₂ / O₂ & Temperature Validation Unit, 115V / 230V

Heating optimization plates
Item Code	Model Code	Description
1320003	MRA-FD	Heating optimization plate for Falcon® Dishes
1320004	MRA-ND	Heating optimization plate for NUNC™ Dishes
1320070	MRA-VD	Heating optimization plate for Vitrolife® Dishes
1320099	MRA-NID	Heating optimization plate for Nipro™ Dishes
1320100	MRA-LD	Heating optimization plate for LifeGlobal® GPS Dishes
1320101	MRA-PD	Heating optimization plate without footprint for Plain Dishes
1320118	MRA-OD	Heating optimization plate for Sparmed - Oosafe®
1320507	MRA-BIRR	Heating optimization plate for BIRR Dishes
