Mini MIRI® Dry Incubator

The Mini MIRI® Dry incubator is a two-chamber mini bench top incubator that takes after the classic MIRI® Multiroom incubator. This mini version of the MIRI® is a perfect-fit for IVF laboratories that prioritize on footprint and affordability.

Embryo Culture

For Embryo Culture

Features

Independent chambers

Compatible with Large Variety of Embryo Culture Dishes

Fast Temperature and Gas Recovery

Continuous pH monitoring (Optional)

Built in Tri-Gas Mixer

Continuous External Validation on Gas and Temperature

Writable Heated Lids

LED display

Data Logger

Small Footprint

Get a Quote Download Catalogue Watch Video
Product Details Parts of the Mini MIRI® Dry Incubator Data Logger Software General Specifications Ordering Information Literature & Resources

Parts of the Mini MIRI® Dry Incubator

Parts of the Mini MIRI® Dry Incubator

Recirculating Gas for Minimal
Gas Consumption

The Mini MIRI® Dry Incubator is a dry IVF bench top incubator that can recirculate gas inside the incubator and is compatible with a HEPA/VOC filtration system unlike other humidified IVF incubators. Gas inserts (whether pure N2 and CO2 or premixed gas) first go through the tri-gas mixing chamber to achieve the set CO2 and O2 gas concentrations by the user and then into the HEPA/VOC filter before entering the incubator chambers. After this, gas now enters a UV Sterilization (254nm) table before going back to the tri-gas mixing chamber and recirculates the gas. This system ensures that there is minimal gas consumption even with lid openings of the incubator chambers while maintaining the recirculating air clean and safe for the embryo samples.

Recirculating Gas for Minimal Gas Consumption

Data Logger Software

Data Logger Software

The Mini MIRI® Dry Incubator comes with a data logger software that monitors the temperature, gas concentration, gas input pressure, gas flow rates, and alarms. All real-time parameters can be viewed conveniently in graphs when the Mini MIRI® is connected to a PC and the data logger software can also monitor multiple incubators at the same time. Weekly reports can be exported for the users' convenience.

data logger software
data logger software alarm
data logger software temperature

General Specifications

Specifications Mini MIRI® Dry
Overall Dimensions (W x D x H) 525 x 420 x 220 mm (20.7 x 16.5 x 8.7")
Weight 22 kg
Power Supply 115 VAC or 230 VAC, 50/60 Hz
Power Consumption 90 W
Temperature Control Range 25- 40 °C
N2 Gas Consumption <12 L/hr
CO2 Gas Consumption <2 L/hr
Gas Pressure 0.4 to 0.6 bar
Shipping Weight 32 kg
Shipping Dimensions 700 x 600 x 470 mm (27.6 x 23.6 x 18.5 ")

Ordering Information

Mini MIRI® Dry Incubator
Item Code Model Code Description
Unit
2070143 MRI-MINI-D-8 Mini MIRI® Dry, without Humidification, 230V, 50/60Hz
2070144 MRI-MINI-D-9 Mini MIRI® Dry, without Humidification, 115V, 50/60Hz
2070145 MRI-MINI-SS-D-8 Mini MIRI® Dry with SAFE Sens for pH monitoring, 230V, 50/60 Hz
2070146 MRI-MINI-SS-D-9 Mini MIRI® Dry with SAFE Sens for pH monitoring, 115V, 50/60 Hz
Accessories
1081277 MRA-SS-SV2 SAFE Sens SV2 Sensor, Pack of 10 pieces (shelf-life 12 months)
1081278 MRA-SS-QC2 SAFE Sens QC2 Alignment Tool
1320191 MRA-SS-TS SAFE Sens TrakStation, a tablet with SAFE Sens Software, for pH monitoring.
1320003 MRA-FD Insert for Falcon® Dishes
1320004 MRA-ND Insert for Nunc™ Dishes
1320070 MRA-VD Insert for Vitrolife Dishes
1320099 MRA-NID Insert for Nipro™ Dishes
1320100 MRA-LD Insert for LifeGlobal® GPS Dishes
1320101 MRA-PD Insert Without Footprint for Plain Dishes
1320118 MRA-OD Insert for SparMED Oosafe®
1320219 MRA-FD-SS Insert for Falcon® Dishes, with hole for SAFE Sens
1320220 MRA-ND-SS Insert for Nunc™ Dishes, with hole for SAFE Sens
1320221 MRA-VD-SS Insert for Vitrolife Dishes, with hole for SAFE Sens
1320222 MRA-NID-SS Insert for Nipro™ Dishes, with hole for SAFE Sens
1320223 MRA-LD-SS Insert for LifeGlobal® GPS Dishes, with hole for SAFE Sens
1320224 MRA-PD-SS Insert Without Footprint for Plain Dishes, with hole for SAFE Sens
1320225 MRA-OD-SS Insert for SparMED Oosafe®, with hole for SAFE Sens
