Mini MIRI® Humidity Incubator

Get a Quote Catalogue
Mini MIRI® Humidity Incubator Front Right
Mini MIRI® Humidity Incubator Front Left
Mini MIRI® Humidity Incubator Right

Mini MIRI® Humidity Incubator

The Mini MIRI® Humidity Incubator is a humidified mini benchtop incubator built on the robust and reliable MIRI® design. The compact design and direct heat regulation help prevent vapor condensation and further translate to faster temperature and gas recovery.

Embryo Culture

For Embryo Culture

Features

Independent chambers

Compatible with Large Variety

Fast Temperature and Gas Recovery

Continuous pH monitoring (Optional)

Built in Tri-Gas Mixer

Continuous External Validation on Gas and Temperature

Get a Quote Download Catalogue Watch Video
Product Details Parts of the Mini MIRI® Humidity Incubator Data Logger Software General Specifications Ordering Information Literature & Resources

Parts of the Mini MIRI® Humidity Incubator

Parts of the Mini MIRI® Humidity Incubator

Recirculating Gas for Minimal
Gas Consumption

The Mini MIRI® Humidity Incubator is a humidified mini bench top incubator that uses either premixed gases or pure gas (N2 and CO2) inserts that pass through a tri-gas mixing chamber to ensure precise gas concentrations before entering the incubator chambers. Afterward, this gas recirculates and goes again through the gas mixing chamber which helps in minimizing gas consumption.

Recirculating Gas for Minimal Gas Consumption

Data Logger Software

Data Logger Software

The Mini MIRI® Humidity Incubator comes with a data logger software that monitors the temperature, gas concentration, gas input pressure, gas flow rates, and alarms. All real-time parameters can be viewed conveniently in graphs when the Mini MIRI® is connected to a PC and the data logger software can also monitor multiple incubators at the same time. Weekly reports can be exported for the users' convenience.

data logger software
data logger software alarm
data logger software temperature

General Specifications of the Mini MIRI® Humidity Multiroom Incubator

Overall Dimensions (W x D x H) 525 x 420 x 230 mm (22.7 x 16.5 x 9")
Weight 22 kg (48.5 lbs)
Material Mild steel / Aluminum / PET / Stainless steel
Power Supply 115V 60Hz or 230V 50Hz
Power Consumption 160 W
Temperature Control Range 24.9 - 40 °C
*CO2 Gas Consumption <4 Liters per hour
**N2 Gas Consumption <12 Liters per hour
Gas Input Pressure
 0.4 to 0.6 bar (5.80 - 8.70 PSI)
Operating Altitude Up to 2000 meters (6560 feet or 80kPa - 106kPa)
Shipping Weight 30 kg (66.1 lbs) (Including the pallet's weight)
Shipping Dimensions 630 x 525 x 500 mm (24.8 x 20.7 x 19.7") (device on the pallet)

* Under normal condition (CO2 set point reached at 6.0%, all lids closed)
** Under normal condition (O2 set point reached at 5.0%, all lids closed)

Ordering Information

Mini MIRI® Humidity Multiroom Incubator
Item Code Model Code Description
Devices
2070155 MRI-MINI-H-8 Mini MIRI® Humidity Multiroom Incubator, 230V, 50/60Hz
2070156 MRI-MINI-H-9 Mini MIRI® Humidity Multiroom Incubator, 115V, 50/60Hz
Accessories
1320142 MRI-DATA Datalogger Package with an Intel® NUC Box, monitor, etc.
Heating optimization plates
Item Code Model Code Description
1320003 MRA-FD Heating optimization plate for Falcon® Dishes
1320004 MRA-ND Heating optimization plate for NUNC™ Dishes
1320070 MRA-VD Heating optimization plate for Vitrolife® Dishes
1320099 MRA-NID Heating optimization plate for Nipro™ Dishes
1320100 MRA-LD Heating optimization plate for LifeGlobal® GPS Dishes
1320101 MRA-PD Heating optimization plate without footprint for Plain Dishes
1320118 MRA-OD Heating optimization plate for Sparmed - Oosafe®
1320507 MRA-BIRR Heating optimization plate for BIRR Dishes

Literature & Resources
